Versatile Centrifuge

Velocity 14R Pro

The Velocity 14R Pro centrifuges protects your sample by refrigeration. It features a compact footprint and provides the flexibility to alternate from micro-volume centrifugation to medium-volume centrifugation at an impressive maximum speed of 14,000 RPM / 21,780xg.

https://dynamica-sci.com/wp-content/uploads/2023/10/Dynamic-Velocity-18_17_14-Brochure-WEB-3.pdf

https://dynamica-sci.com/wp-content/uploads/2021/11/Dynamica-V14-Pro-instruction-manual-202011.pdf

Features

Auto Rotor Recognition

Automatic rotor recognition and confirmation once centrifugation has commenced, including rotational speed calculation and optimum temperature control. Furthermore new rotors can be easily loaded onto the on-board database as they are introduced.

Auto-Lock Rotor

With the Velocity 14R Pro you simply need to place the rotor onto the drive shaft. The auto lock and secure mechanism performs the rest. Once centrifugation is complete, simply lift the rotor off the drive shaft. Quick, easy, efficient and safe.

auto lock rotor ver2.2

High imbalance tolerances

Innovative motor engineering and mounting (including a flexible drive shaft) allow for greater imbalance tolerances, so much so that samples can be balanced simply by eye. No more weighing – just fill tubes or bottles to within 5mm of each other.

Fast Acceleration And Deceleration

The innovative high-torque drive technology effortlessly accelerates even the heaviest rotors to terminal velocity quickly and efficiently. A full load will achieve maximum velocity within a few minutes. 10 pre-set acceleration and 11 pre-set deceleration profiles (including coasting deceleration) ensure the best separation, even for the most delicate density gradients.

Quiet Operation

Noise abating insulation in the console, including lower noise fans, combine to reduce the audible operating noise to ≤58dB.

Specification

Model Velocity 14R Pro
Maximum Speed 14,000RPM
Maximum RCF 21,780 xg
Maximum Capacity 300 ml (6 x50 ml)
Driving System Brushless DC Motor
Acceleration / Deceleration mode 1-10 stages / 0-10 Stage
Temperature Setting Range -20°C to +40°C
Refrigerant R134a
Timer  Running time from 1 min to 99 hours 59 mins. or “HOLD function”
Program memory 9 Programs
Dimensions 650 x 520 x 540 mm (WxDxH)
Weight Approx. 60 kg
Packing Size 650 x 520 x 540 mm (WxDxH)
Main Power  220V Single phase, ~220-240V±10%, 50/60Hz±1Hz, 1500VA110V Single phase, ~110V ±10%, 60Hz±1Hz, 1500VA
Ordering Number 0035660 (220V 50/60Hz)

https://dynamica-sci.com/wp-content/uploads/2023/10/Dynamic-Velocity-18_17_14-Brochure-WEB-3.pdf

https://dynamica-sci.com/wp-content/uploads/2021/11/Dynamica-V14-Pro-instruction-manual-202011.pdf
