The Velocity 30R is a high-speed, benchtop refrigerated centrifuge capable of running swing out and angle rotors. With maximum 30,000rpm as well as maximum 6x250ml capacity, it will fulfill your entire process requirements.
With a high speed and wide selection of rotors, the Velocity 30R is suitable for a variety of applications including microbiology, biochemistry, chemistry, environmental studies and more.
https://dynamica-sci.com/wp-content/uploads/2021/11/Dynamica-Velocity-30R.pdf
https://dynamica-sci.com/wp-content/uploads/2021/11/V30R-Instruction-manual-2020.10.06.pdf
The maximum speed of Velocity 30R is 30,000rpm or 65,395 xg.
You can select between swing out, microplate and fixed angle. This allows you to spin sample quantities from microlitres up to 250 milliltire.
If the rotor is not loaded equally, the drive will automatically turn off during accelerate and decelerate to a standstill. This ensures the centrifuge will not spin if imbalanced therefore protecting both the machine and the operator.
Compared with the traditional brush drive, the brushless induction drive requires very little maintenance.
With less contact, not only is there a quieter operation but also reduced wear-and-tear damage, extending the product lifespan.
The acceleration and deceleration rates can be set between 0-9, totaling 10 levels. You can choose speed based on your sample’s characteristics.
A powerful, non-CFC compressor cools the chamber quickly whilst maintaining the rotor at a set temperature during centrifugation. The twin cooling fans – one for the compressor and motor – dissipate heat quickly to improve cooling efficiency and extend the motor lifespan.
Specification
| Model | Veclocity 30R |
|---|---|
| Maximum Speed | 30,000 rpm |
| Maximum RCF | 65,395 xg |
| Maximum Capacity | 1,500 ml (6 x250 ml) |
| Driving System | Maintenace-free induction motor |
| Speed Control Range | 200 rpm to 30,000 rpm (10RPM increments) |
| Acceleration / Deceleration mode | 0-9 stages |
| Temperature Setting Range | -20°C to +40°C in steps of 1°C |
| Refrigerant | CFC-free refrigeration system |
| Timer | Running time from 10 sec to 99 hours 59 mins. or “Quick” |
| Program memory | Store 99 complete centrifuge runs |
| Noise Level | < 65 dB (A) |
| Dimensions | 715 x 510 x 420 mm (WxDxH) |
| Weight | Approx. 91 kg |
| Main Power | AC: 230V/50-60Hz 1 ph (Voltage Fluctuation ±10%) |
| Ordering Number | D-V30R30200V03 |
