IKA RV 10 auto pro V-C Rotary Evaporators

Rotary Evaporators

RV 10 auto pro V-C

The RV 10 auto offer all properties required for efficient, safe, and cost-effective operations. These include automatic control of the vacuum and cooling water volume. Its intuitive handling concept quickly leads its users to their desired results in every application. Thanks to specially designed glass guides, the transparent coated vertical condenser makes extremely efficient use of the 1600 cm² cooling surface. Thanks to its extended ramp programming capability, the RV 10 auto allows users to carry out customized procedures. Other innovative features, such as smooth start, interval mode, right-left operation in interval mode, or the timer function for time-lapse tests, make everyday work in the laboratory much easier.

RV 10 auto pro V-C Rotary Evaporators

Safety is ensured by the motorized lift with safety-stop function that automatically lifts the evaporation flask out of the heating bath in the case of power failure. Additional safety for users is provided by individually adjustable temperature safety circuits, protection against boiling dry, adjustable end-point recognition to prevent glass breakage, and a locking function. The receiving flask and the condenser are also available in coated versions. The USB port or the RS-232 interface enable remote control with the IKA “labworldsoft” software package and an update option with the firmware update tool. The device comes complete with vacuum hoses and hose connectors for your in-house cooling water supply. The new IKA Vacstar digital included in the package is controlled directly from the drive unit of the RV 10 auto via the data cable provided.

4-liter heating bath with a heating temperature range of RT to 180 °C
automatic boiling point detection
integrated vacuum controller
integrated solvent library with 40 preset solvents and expansion option
bright, high-contrast, TFT, color-graphic control panel
universal safety heating bath
optimized heating bath volume for rapid achievement of working temperature
heating bath with ergonomic handles
temperature safety circuit
boil-dry protection
condenser with 1600 cm² cooling surface and low space requirements
evaporation flasks available with coated or uncoated glass
intuitive handling concept with simple menu navigation
programming option for up to ten individual procedures
smooth start
right or left rotation
timer function
end-point recognition
push-off mechanism for tightly-fitting flasks
digital interfaces: USB port and RS-232 interface for remote control
multi-language operating system
automatic cooling water management
automatic ventilation
automatic heating bath management

Warranty
By registering your devices online at www.ika.com/register, you can extend the warranty of your products free of charge. For rotary evaporators and heating baths, the standard warranty is two years, plus three additional years after registration (2+3). For peripheral devices included in the package (vacuum pump and chiller), the additional warranty is one year (2+1).

Scope of delivery
