ECO-FRIENDLY & CLEAN For a Beautiful Earth

Product concepts underlying Hitachi's U-5100 UV-Visible Spectrophotometer is ECO-FRIENDLY & CLEAN. The Ratio Beam Spectrophotometer U-5100 delivers a compact, lightweight package with remarkable power savings and a long life for its light source. The U-5100 incorporates every aspect of the technological features of Hitachi's reliability-proven spectrophotometers while achieving our ultimate goal to create a spectrophotometer that is ECO-FRIENDLY & CLEAN and provides SUPERIOR PERFORMANCE​



Tags: Hitachi Ratio Beam Spectrophotometer U-5100 ​Sigmatech Inc. Philippines
Key Industries: Batteries, Pharmaceutical, Water and Wastewater and more.

ECOLOGY: Incorporates a Xenon flash lamp, which is an environmentally friendly, low-power consumption, long-life light source.

Adoption of a Xenon flash lamp

By adopting a long-lasting Xenon flash lamp, the product delivers a long life for its lamp, eliminating the need for periodic lamp replacement that was necessary in previous model*1.

Energy saving design

Through control of the Xenon flash lamp that emits pulses only during measurement, power consumption is reduced by 70% compared with previous model.

Reduced measurement time

The automatic switching of 6 cells by using an automatic 6-cell turret and a high-speed scanning (12,000 nm/min) deliver a substantial reduction in measurement time (approximately 60% reduction). The examples shown in the figure compare*2 the amount of time required to measure 100 samples (5 wavelengths × 20 samples) with a previous model*1, based on biological analyses and quality control on food products.

DESIGN:User-friendly, compact, lightweight design

Compact, lightweight design

The U-5100 features a 38% smaller footprint, and a 52% reduction in weight compared with a previous model*1, which makes it easier to secure an adequate installation space.

EASY OPERATION: Performing at a Higher Level! The operation of the U-5100 is very easy minimizing the operator training time

The standard configuration of an automatic 6-cell turret makes performing measurements a breeze. As part of its standard configuration, the system is equipped with a 6-cell turret which accommodates up to six 10-mm rectangular cells.
The system can measure a maximum of six calibration solutions and sample solutions*3, which reduces measurement time.

*1Hitachi Ratio Beam Spectrophotometer U-1900*2Measuerment time does not include the amount of time required by an operator to load a cell on a holder or a turret.*3Including samples for setting an auto zero (the operation of adjusting the absorbance to zero).

Specification

ItemDescription
OpticsSeya-Namioka mount monochromator, ratio beam
Wavelength range190 to 1,100 nm
Spectral bandpass5 nm
Light sourceXenon(Xe) flash lamp
DisplayLED with backlight
120 mm × 90 m, 320dot × 240dot
Cell6 cell turret(Automatic) (Single cell holder is optional)
Size (main unit)355 (W) × 425 (D) × 235 (H) mm
Weight (main unit)13 kg
Power supply/
Power consumption
100, 115, 220, 230 or 240 V, 50/60 Hz 60 VA

See More



Sigmatech Inc. Philippines is the leading provider of cutting-edge laboratory equipment crucial for a wide range of applications, including Quality Assurance/Quality Control (QA/QC), Metrology, Research and Development (R&D), Failure Analysis, Environmental and Chemical Analysis, and Process Control. Serving diverse industries in the Philippines, such as Semiconductor/Electronics, Pharmaceutical, Mining, Energy, and more, we are your go-to source for top-quality equipment, including Ratio Beam Spectrophotometers in the Philippines. About us
Features

ECOLOGY: Incorporates a Xenon flash lamp, which is an environmentally friendly, low-power consumption, long-life light source.

Adoption of a Xenon flash lamp

By adopting a long-lasting Xenon flash lamp, the product delivers a long life for its lamp, eliminating the need for periodic lamp replacement that was necessary in previous model*1.

Energy saving design

Through control of the Xenon flash lamp that emits pulses only during measurement, power consumption is reduced by 70% compared with previous model.

Reduced measurement time

The automatic switching of 6 cells by using an automatic 6-cell turret and a high-speed scanning (12,000 nm/min) deliver a substantial reduction in measurement time (approximately 60% reduction). The examples shown in the figure compare*2 the amount of time required to measure 100 samples (5 wavelengths × 20 samples) with a previous model*1, based on biological analyses and quality control on food products.

DESIGN:User-friendly, compact, lightweight design

Compact, lightweight design

The U-5100 features a 38% smaller footprint, and a 52% reduction in weight compared with a previous model*1, which makes it easier to secure an adequate installation space.

EASY OPERATION: Performing at a Higher Level! The operation of the U-5100 is very easy minimizing the operator training time

The standard configuration of an automatic 6-cell turret makes performing measurements a breeze. As part of its standard configuration, the system is equipped with a 6-cell turret which accommodates up to six 10-mm rectangular cells.
The system can measure a maximum of six calibration solutions and sample solutions*3, which reduces measurement time.

*1
Hitachi Ratio Beam Spectrophotometer U-1900
*2
Measuerment time does not include the amount of time required by an operator to load a cell on a holder or a turret.
*3
Including samples for setting an auto zero (the operation of adjusting the absorbance to zero).

Specification

Item Description
Optics Seya-Namioka mount monochromator, ratio beam
Wavelength range 190 to 1,100 nm
Spectral bandpass 5 nm
Light source Xenon(Xe) flash lamp
Display LED with backlight
120 mm × 90 m, 320dot × 240dot
Cell 6 cell turret(Automatic) (Single cell holder is optional)
Size (main unit) 355 (W) × 425 (D) × 235 (H) mm
Weight (main unit) 13 kg
Power supply/
Power consumption
100, 115, 220, 230 or 240 V, 50/60 Hz 60 VA

See More



Sigmatech Inc. Philippines is the leading provider of cutting-edge laboratory equipment crucial for a wide range of applications, including Quality Assurance/Quality Control (QA/QC), Metrology, Research and Development (R&D), Failure Analysis, Environmental and Chemical Analysis, and Process Control. Serving diverse industries in the Philippines, such as Semiconductor/Electronics, Pharmaceutical, Mining, Energy, and more, we are your go-to source for top-quality equipment, including Ratio Beam Spectrophotometers in the Philippines. About us
