Product features
Large Color LCD Touch Panel
A large 8.4″ touch panel screen enables the user to input text easily. Selecting functions from the menu can be operated intuitively. The protective film can be replaced to protect it from scratches and wear over the long term.

LCD Display Adjustable in 16 Positions
Each user can adjust the angle as he/she likes. The position can be locked so that it will not move when the screen is pressed.

Four Types of Titrations in Parallel
By adding a titration station and stirrer, four types of titrations can be carried out in parallel. (Karl Fischer titrator can also be added)

Built-in Thermal Printer
Equipped with a built-in thermal printer with a paper roll 58-mm wide, which can be set up simply by inserting the paper roll and closing the cover.

USB/LAN Port
Approximately 9,900 results can be stored on a USB memory stick. With optional software, the user can view the data on a PC or use a recalculation function. With a LAN connection, the user can also view the data on a Web browser.

User Authentication Settings
User restrictions enable the security improvement as well as the prevention of inadvertent changes to, for example, measurement conditions.

Status Indicator with 3 LED Colors
Colored lights allow the user to confirm the status of operation from a distance. The user will also be alerted to unexpected problems right away.

Easy Replacement of Buret Head
Simply sliding toward the user, Buret Head can be removed together with the reagent bottow just with one hand. With multiple buret heads, the user can quickly manage different titrants simply by switching them.

Economical Purge Function
Discharging/charging at the top end of the syringe is repeated. Reagents can be replaced automatically, which greatly reduces waste fluid. The number of economical purge cycles can be set from 1 to 99.

Forty Rotation Speeds Can Be Set
Rotation can be adjusted manually in fine increments shown by LED bars$2014it is easy to see and understand. (Four increments per each bar)

Two-color LED display of operating status
The operating status can be checked from a distant location.

Specification
| Parallel measurement | Up to four titration stations are connectable. (by optional titration station (and stirrer)) |
|---|---|
| Titration methods | Potentiometric titration |
| Measuring range | pH: 0 to 14, mV: -2000 to +2000 mV |
| Titration mode | Learn titration, Inflection-point detection, Set-point detection, Set point/Inflection-point detection, Cross-point (F, B, V1, V2) detection, Neutralization values in petroleum products (Oil1, 2) Other functions: pH-Stat (1, 2), pH measurement, Dispensing, Calculation, pKa measurement |
| Endpoint detection mode | Auto-detection using a second derivative (with smoothing function), Set-point detection, Cross-point detection |
| Number of endpoints detected | Up to 5 end points with a Learn titration file or linked method files |
| Display | 8.4 inch color LCD touch panel |
| Displayed content | Titration conditions, Data per drip, Titration results, Titration curve, Differential curve, List of titration results, Statistics calculation results, Condition settings display, Real-time display of fluid temperature during titration (when thermistor electrode is connected) |
| Memory data capacity (Each titration station) | Built-in memory: 100 data points USB flash memory: (≧256MB) Maximum capacity approx. 9,900 data points |
| Settings input method | Key touch input (English guide displayed) |
| Sample data | Sample No.: 2 digits, ID code: 16 alphanumeric characters |
| Master file | Titration execution files: 51 files |
| Conditions file | 51 files (method parameters, constant files, control mode files) |
| Number of linked condition file | 9 files (up to 5 files in case of titration files linkage) |
| Titration control mode file | Standard files: 51; Neutralization value files in petroleum products: 51; Manufacturer settings modes (0$201311), Blank modes (12$201319), User setting mode (20$201350) |
| Constant file (settings parameter of concentration calculation constant) | 51 files K, L (constants), F (factors), M or N (molarity or normality), B (blank mL), S (sample size), T (temperature °C) |
| Sample files | 99 files (Sample No., ID code, Master file and Sample size) |
| Auto input function | Function to automatically set titration results to constant parameters (blank, factor, etc.) . Condition files for automatic input can be designated. |
| Calculation function | Concentration calculation, Statistics calculations, pH automatic compensation |
| Branching function | After measuring the potential prior to titration, branching into maximum 2 condition files |
| GLP-compliant function | 1) Buret precision check, 2) Electrode check, 3) Buret use frequency (display/print), 4) Electrode maintenance (display/print), 5) Reagent level display and alarm |
| Printer | Built-in thermal printer (Paper roll width: 58 mm) |
| External input/output | RS-232C: 1 port (For balance or computer connection), LAN: 1 port, USB flash memory stick: 1 port |
| Power supply | AC100-240 V±10 % 50/60 Hz 60 VA (MC-3000 only) A power cable is not included in this product. (*1) |
| Dimensions / weight | 235(W) × 400(D) × 250(H) mm / Approx. 6.5 kg (MC-3000 only) |
* The power inlet of this product complies with IEC60320 C14. Please prepare a power cable that can be connected to this power inlet.
